High Input Impedance Chopper-stabilized Analog Front-end Based on Variable-capacitor Calibration for Bio-consumer Electronics
Abstract
Analog front-end (AFE) circuits for bio-consumer electronics require ultra-high input impedance to ensure robust bio-potential acquisition under interference. This paper presents a chopping-stabilized AFE featuring an automatic input-impedance enhancement technique based on a positive feedback loop (PFL) with a continuously tunable variable-capacitor. An oscillation-detection-based calibration loop dynamically adjusts the PFL to compensate front-end parasitic capacitance, driving the system from an unstable condition to an optimal stable boundary with maximized input impedance while avoiding over-compensation. To improve calibration robustness, a frequency ripple suppression scheme is introduced, enabling precise control of the variable-capacitor independent of input frequency variations. The proposed variable-capacitance technique provides femtofarad-level resolution without relying on discrete capacitor arrays, achieving wide tuning range and high linearity. Fabricated in a 0.18 μm CMOS process, the AFE achieves an input impedance of 46.3 GΩ at 50 Hz, representing an 83× improvement over conventional approaches. The prototype occupies 0.71 mm², achieves a mid-band gain of 40 dB, an input-referred noise of 0.93 μVrms, and a power consumption of 3.48 μW. Experimental EEG and ECG measurements using comfortable dry electrodes validate the effectiveness of the proposed AFE for bio-consumer electronic applications.
